Loctite 290 Strength Threadlocker, 10 mL Bottle, Green 10 milliliters
Customize
Loctite 290 series medium-strength green threadlocker in a 10 mL bottle. Low-viscosity, capillary-action liquid ideal for pre-assembled bolts up to 1/2" (up to 12 mm). Series: 290 (Series Part Number: 29021, Manufacturer part: 233731, Model: 442-29021). Container Size: 10 ml (smaller than 1 oz). Full cure time approx. 24 hours. Maximum operating temperature 300 °F. Removal: hand tool or heat. Breakaway torque: 90 Lb./Inch (M10 steel nuts & bolts after 24 hr at 22 °C). Environmental: non-food contact. Standards: ANSI 61; ASTM D-5363; CFIA Approved; MIL-S-46163A Type II Grade M; MIL-S-46163A Type II Grade R; NSF 61; NSF P1. Specific uses include instrumentation screws, electrical connectors, set screws, and sealing porosities in welds and metal parts. Material: Dimethacrylate Ester. Package dimensions and weight available for shipping calculations.
- Country of Origin : United States
- Package Weight: 0.018 kilograms
- Protects threads from rust and corrosion
- Package Dimensions: 12.801 H x 3.2 L x 4.597 W (centimeters)
Specifications:
| Materials & Construction | |
| Color | Green |
| Material | Dimethacrylate Ester |
| Product Details | |
| Breakaway Torque (Lb./Inch) | 90 (M10 Steel Nuts & Bolts After 24 Hr At 22 Deg c) |
| Color | Green |
| Container Size | 10 ml |
| Container Size Range | Smaller Than 1 oz |
| Container Type | Bottle |
| Environmental | Non-Food Contact |
| Fastener Size Range | Up To 1/2; Up To 12.00 mm |
| Form | Liquid |
| Full Cure Time (Hours) | 24.00 |
| Item Form | Liquid |
| Item model number | 442-29021 |
| Maximum Operating Temperature F | 300.00 |
| Product Service Code | 8040 |
| Removal Method | Hand Tool; Heat |
| Series | 290 |
| Series Part Number | 29021 |
| Special Feature | Low Viscosity and Capillary Action, Military Grade Compliance |
| Specific Uses For Product | Electrical, Metalworking, Repair |
| Standards | Ansi 61; Astm D-5363; Cfia Approved; Mil-S-46163a Type Ii Grade M; Mil-S-46163a Type Ii Grade R; Nsf 61; Nsf p1 |
| Strength | Medium |
| Sizing & Dimensions | |
| Height | 3.54 inches |
| Length | 0.79 inches |
| Product Dimensions | 0.79 x 0.79 x 3.54 inches |
| Size | 10 ml |
| Weight | 0.63 ounces |
| Width | 0.79 inches |
| Technical Specifications | |
| Breakaway Torque (Lb./Inch) | 90 (M10 Steel Nuts & Bolts After 24 Hr At 22 Deg c) |
| Fastener Size Range | Up To 1/2; Up To 12.00 mm |
| Full Cure Time (Hours) | 24.00 |
| Maximum Operating Temperature F | 300.00 |
| Removal Method | Hand Tool; Heat |
| Specific Uses For Product | Electrical, Metalworking, Repair |
| Standards | Ansi 61; Astm D-5363; Cfia Approved; Mil-S-46163a Type Ii Grade M; Mil-S-46163a Type Ii Grade R; Nsf 61; Nsf p1 |
