Enerpac RC-101 Single-Acting Alloy Steel Hydraulic Cylinder with 10 Ton Capacity. Product details: Portable Hydraulic Cylinder: Single Acting, 2.24 cu in Oil Capacity; Rod Dia: 1.5000 in; Retracted Length: 3.5300 in; Extended Length: 4.5300 in; Actuation: Single Acting; Oil Capacity: 2.24cu-in; Lowered Height: 3.5300; Plunger Type: Solid; Body Material: Steel; Plunger Internal Thread Size: 10-24; Series: RC; Collar Thread: 2-1/4 - 14; Plunger Internal Thread Length: 0.2500; Maximum Height (Inch): 4.5300. Marketed as ENERPAC 10 TON CYLINDER, S/A (RC101). Compact, durable alloy/steel construction for heavy-duty lifting applications.
Specifications:
| Materials & Construction |
| Body Material | Steel |
| Material | Steel |
| Plunger Type | Solid |
| Product Details |
| Actuation | Single Acting |
| Body Material | Steel |
| Collar Thread | 2-1/4 - 14 |
| Item model number | RC-101 |
| Lowered Height | 3.5300 |
| Oil Capacity | 2.24cu-in |
| Plunger Internal Thread Length | 0.2500 |
| Plunger Internal Thread Size | 10-24 |
| Plunger Type | Solid |
| Series | Rc |
| Unspsc Code | 27121602 |
| Sizing & Dimensions |
| Extended Length | 4.5300 |
| Height | 4.6000 inches |
| Length | 6.0000 inches |
| Maximum Height (Inch) | 4.5300 |
| Product Dimensions | 3.7 x 4.6 x 4.6 inches; 4 Pounds |
| Product Weight | 4.0000 |
| Retracted Length | 3.5300in |
| Rod Diameter | 1.5000in |
| Weight | 4 pounds |
| Width | 4.3200 inches |
| Technical Specifications |
| Is Discontinued By Manufacturer | No |
| Item model number | RC-101 |
