Victron Energy MultiPlus-II Pure Sine Wave Inverter Charger
Customize
The Victron Energy MultiPlus-II inverter charger family delivers combined inverter and charger functionality with a focus on reliable, uninterrupted AC power. Common features include pure sine wave output, PowerAssist to prevent overload of limited AC sources, PowerControl with external current sensing (max. 32A) to optimize self-consumption, and UPS-capable transfer in under 20 ms. MultiPlus-II models support parallel operation (up to 6 units), configurable three-phase systems, built-in anti-islanding protection and an expanding list of country approvals. Designed for integration with Energy Storage Systems (ESS) and solar energy systems, the MultiPlus-II family also supports remote monitoring and control via Cerbo GX and the VRM portal for local and remote system management.
- PROFESSIONAL INVERTER CHARGER: The MultiPlus-II is ideally suited for professional marine, yachting, vehicle and land based off-grid applications
- PARALLEL OPERATION: Up to 6 Victron Energy MultiPlus-II Pure Sine Wave Inverter units can operate in parallel to achieve higher power output, In addition to parallel connection, three units can be configured for three-phase output.
- POWER WITHOUT INTERRUPTION: In the event of a grid failure, or when shore or generator power is disconnected, the Victron inverter is activated fast, within 20ms, and takes over the supply to the connected loads
- POWER ASSIST: With the unique Power Assist feature the MultiPlus-II solar inverter will prevent overload of a limited AC source, such as a generator or shore power connection
- VICTRON ENERGY PURE SINE WAVE INVERTER: The MultiPlus-II inverter charger combines the functions of the MultiPlus and the MultiGrid. It has all the features of the MultiPlus, plus an external current transformer option to implement PowerControl and PowerAssist and to optimize self-consumption with external current sensing (max. 32A). It also has all the features of the MultiGrid with built-in anti-islanding and an increasingly long list of country approvals.
Specifications:
| Product Details | |
| Included Components | Victron Energy - MultiPlus-II 48/3000/35-50 120V |
| Model Name | Victron Energy - MultiPlus-II 48/3000/35-50 120V |
| Sizing & Dimensions | |
| Height | 5.5 inches |
| Length | 19.6 inches |
| Product Dimensions | 10.5 x 5.5 x 19.6 inches; 50.7 Pounds |
| Weight | 50.7 pounds |
| Width | 10.5 inches |
| Technical Specifications | |
| Power Assist / Power Control | Implemented (external current transformer option, max. 32A) |
