ARP 1342001 Black Oxide 12-Point Intake Manifold Bolt
ARP 134-2001 black oxide chromoly intake manifold bolt kit for Small Block Chevy — 12 fully threaded 3/8-16 12-point bolts with painted finish and manufacturer warranty.
Non-returnable
$30.42
Customize
UPC
672036001704 Available Quantity
107 GSA Item
No GSA Compliant
Yes Product Details
ARP 134-2001 Black Oxide 12-Point Intake Manifold Bolt kit for Small Block Chevy. This hardware kit includes 12 fully threaded 3/8-16 chromoly bolts finished in black oxide/painted exterior to secure intake manifolds. Bolts feature a 12-point/hex head style, thread class 1A, right-hand UNC threads and fully threaded coverage. Material type listed as chromoly with metal type noted as stainless steel; manufacturer grade and item hardness specified as Grade 2. Item dimensions listed as 7 x 5 x 1 inches and item weight provided as 0.26 kilograms (approx. 0.573 pounds). The kit is sold as a set and includes hardware components; manufacturer provides warranty. Suitable for performance engine intake manifold applications on Small Block Chevy.
- Package Weight: 0.65 pounds
- Fit type: Vehicle Specific
- Part number: 1342001
- ARP Intake Manifold Bolt Kit Small Block Chevy P/N 134-2001
Specifications:
| Materials & Construction | |
| Color | Black |
| Exterior Finish | Painted |
| Finish Types | Black oxide |
| Material | Chromoly |
| Material Type | Chromoly |
| Metal Type | Stainless Steel |
| Product Details | |
| Fastener Type | Hexagon Bolt |
| Head Style | Hex |
| Included Components | Hardware Kits - Other |
| Model | 134-2001 |
| Screw Head Style | Hex |
| Set Name | Small Block Chevy Intake Manifold Bolt Kit |
| Thread Coverage | Fully Threaded |
| Warranty Description | Manufacturer Warranty |
| Sizing & Dimensions | |
| Fastener Size | 3/8 inches |
| Height | 1 inches |
| Item Diameter | 0.38 Inches |
| Item Dimensions | 7 x 5 x 1 inches |
| Length | 7 inches |
| Number of Pieces | 12 |
| Product Dimensions | 7 x 5 x 1 inches |
| Size Name | Stock |
| Thread Size | 3/8-16 |
| Weight | 0.573 pounds |
| Width | 5 inches |
| Technical Specifications | |
| Drive System | Rear-Wheel Drive |
| Grade Rating | Ungraded |
| Item Hardness | Grade 2 |
| Manufacturer Grade | Grade 2 |
| Maximum Shear Strength | 580 MPa" or "84,000 psi |
| Screw Point Style | Hex |
| Thread Class | 1A |
| Thread Style | Right Hand |
| Thread Type | Unc |
