JR Products 12095 White Replacement Slide-Out High Current Motor Switch White 1 Count (Pack of 1)
JR Products 12095 white slide-out rocker motor switch — replacement panel-mount switch for automotive use. 12V, 40A continuous (480W), screw terminals, IP54 rated; includes wiring diagram.
Non-returnable
$16.41
Customize
UPC
756815120951 Available Quantity
17 GSA Item
No GSA Compliant
Yes Product Details
JR Products 12095 Replacement Slide-Out High Current Motor Switch (White) is a durable, panel-mount rocker switch designed for high-output motor control. This 12V switch supports 40 Amps continuous (480 watts) and features screw terminals, SPDT terminal configuration, and a large rocker actuator for easy operation. It includes an easy-to-read wiring diagram and is IP54 rated for protection. Contact materials include copper and brass while the body material is plastic. Typical uses include automotive power switching and motor reversing applications. Cutout dimensions: 1.85” x 1.20”. Compatible for use with Part No. 13061. Pack quantity: 1.
- Mom-On/Off/Mom-On
- Use with Part. No. 13061
- 12V 40 Amp continuous
- White
- Cutout: 1.85” x 1.20”
- JR Products Replacement Slide-Out Switch
- High output reversing motor switch
- 40 Amp at 14VDC peak
- White, Pack of 1
Specifications:
| Materials & Construction | |
| Color | White |
| Contact Material | Copper, Brass |
| Material | Plastic |
| Product Details | |
| Actuator Type | Rocker |
| Circuit Type | 1-way |
| Color | White |
| Connectivity Protocol | X-10 |
| Connector Type | Screw Terminals |
| Contact Material | Copper, Brass |
| Contact Type | Normally Open |
| Control Method | Touch |
| Controller Type | Push Button |
| Current Rating | 40 Amps |
| International Protection Rating | IP54 |
| Material | Plastic |
| Material Type | Plastic |
| Model | 12095 |
| Mounting Type | Panel Mount |
| Number of Positions | 2 |
| Operating Voltage | 12 Volts |
| Operation Mode | Off |
| Specification Met | ETL |
| Switch Type | Rocker |
| Terminal | Spdt |
| Wattage | 480 watts |
| Sizing & Dimensions | |
| Height | 1.00 inches |
| Length | 4.38 inches |
| Product Dimensions | 4.38 x 1 x 0.06 inches |
| Product Weight | 0.0800 |
| Weight | 1.28 ounces |
| Width | 2.69 inches |
| Technical Specifications | |
| International Protection Rating | IP54 |
| Specification Met | ETL |
| Wattage | 480 watts |
