Perko 0543DPGBLK Polymer Vented Fill with Straight Neck for 1-1/2" Hose - Gas-Marked Black Polymer Cap
Customize
0543 Vented Fill f/1-1/2" Hose - Straight Neck - Gas - Black. Black Polymer Cap with Black Polymer Body. Black Polymer Strap. Integral Tank Vent with Flame Arrestor and Anti Surge Valve. Technical Information: For Hose Size: 1-1/2". For Vent Hose: 5/8" O.D. Flange: 3-5/8". Neck Length: 2-7/16". Mounting Hole Dia.: 2-1/8". Screw Size: #8. Perko's 0543DPGBLK Vented Fuel Fill is for use with a 1-1/2" hose on gas applications only. This Vented Fuel Fill features a straight neck and a black, polymer strap. It is an integral tank vent with a flame arrestor and anti-surge valve. Ground wire is not required for this fuel fill. It is constructed with black, polymer material for long-lasting use. The outer dimension of the Flange is 3-5/8" and the neck length is 2-7/16". The mounting hole diameter is 2-1/8" and a #8 screw size is required for installation. Use with 1-1/2" hose size and 5/8" vent hoses.
- Fits 5/8" vent hose
- For Hose Size: 1-1/2"
- Integral tank vent with flame arrestor and anti-surge valve
- Black polymer strap
- Black plastic cap with black plastic body
Specifications:
| Materials & Construction | |
| Color | Black |
| Exterior Finish | Plastic |
| Material | Plastic |
| Product Details | |
| Fit Type | Universal Fit |
| Fuel Type | Gasoline |
| Global Trade Identification Number | 00085226051562 |
| Included Components | Great Product |
| Product Grade | like new |
| Style | Modern |
| Warranty Description | Warranty |
| Sizing & Dimensions | |
| Height | 4 inches |
| Length | 10 inches |
| Product Dimensions | 10 x 6 x 4 inches |
| Size | No Size |
| Weight | 5.6 ounces |
| Width | 6 inches |
| Technical Specifications | |
| Fit Type | Universal Fit |
| Style | Modern |
