Ancor 100825 Marine Grade Electrical Primary Tinned Copper Boat Wiring (18-Gauge, Red, 250-Feet)
Customize
Red 18 AWG Tinned Copper Wire - 250'. Ancor Marine Grade wire products are the longest lasting and most rugged available, exceeding UL 1426, ABYC and US Coast guard Charter boat (CFR Title 46) standards. They are constructed with premium vinyl insulation that is rated at 600V, 105°C dry and 75°C wet, stays flexible even in extreme cold (-40°F/C) and resists salt water, battery acid, oil, gasoline, heat, abrasion and ultra-violet radiation. Highest quality ultra flexible (Type 3) tinned copper stranding provides maximum protection against corrosion and electrolysis while resisting fatigue due to vibration and flexing. Wire Gauge: 18 AWG Nominal O.D. (inches): 7/64 Nominal O.D. (mm): 3. WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Features & marketing: They are constructed with premium vinyl insulation that is rated at 600 volts, 105 deg C dry and 75 deg C wet, stays flexible even in extreme cold (-40 deg F/C) and resists salt water, battery acid, oil, gasoline, heat, abrasion and ultra-violet radiation. Exceeds all UL 1426, US Coast Guard Charter boat (CFR title 46) and ABYC standards. Ultra-flexible Type 3 stranding resists fatigue from vibration and provides added corrosion protection. Manufactured from individual copper strands and tinned to perform in the harshest marine environments. 250 Feet of Red 18 AWG marine grade wire.
- They are constructed with premium vinyl insulation that is rated at 600 volts, 105 deg C dry and 75 deg C wet, stays flexible even in extreme cold (-40 deg F/C) and resists salt water, battery acid, oil, gasoline, heat, abrasion and ultra-violet radiation
- Exceeds all UL 1426, US Coast Guard Charter boat (CFR title 46) and ABYC standards
- Ultra-flexible Type 3 stranding resists fatigue from vibration and provides added corrosion protection
- Manufactured from individual copper strands and tinned to perform in the harshest marine environments
- 250 Feet of Red 18 AWG marine grade wire
Specifications:
| Materials & Construction | |
| Color | Red |
| Material | Copper |
| Outer Material | Vinyl insulation |
| Stranding Type | Type 3 tinned copper |
| Product Details | |
| Global Trade Identification Number | 00091887100150 |
| Included Components | Great Product |
| Material | Copper |
| Model Name | 100825 |
| No. of wires | 1 |
| Number of Cable Strands | Multi Strand |
| Size | 250 Feet |
| Style | 18 Awg |
| UPC | 091887100150 |
| Voltage | 600 Volts |
| Warranty Description | Warranty |
| Sizing & Dimensions | |
| Height | 5 inches |
| Length | 7 inches |
| Product Dimensions | 7 x 7 x 5 inches |
| Size | 250 Feet |
| Weight | 2.8 pounds |
| Width | 7 inches |
| Technical Specifications | |
| Compliance | Exceeds UL 1426, ABYC and US Coast Guard CFR Title 46 standards |
| Gauge | 18 Awg |
| Voltage | 600 Volts |
