Ancor 106010 Tinned Copper Wire, 12 AWG (3mm2), Black - 100ft
Customize
Ancor Marine Grade Primary Wire is manufactured from tinned copper stranding for maximum protection against corrosion and electrolysis. Ultra-flexible (Type 3) stranding helps prevent fatigue due to vibration and flexing. Ancor's proprietary premium vinyl insulation stays flexible even in extreme cold (-40° F/ -40° C) and resists salt water, battery acid, oil, gasoline, and ultraviolet radiation. The wire's exclusive insulation is rated at 600 volts, 221° F / 105° C dry and 167° F / 75° C wet, and is engineered to withstand heat and abrasions. Exceeds all UL 1426, US Coast Guard Charter boat (CFR Title 46), and ABYC standards. Features from ProductDatabase: Black 12 AWG Primary Wire - 100'. ANCOR Marine Grade™ wire is manufactured from tinned copper stranding for maximum protection against corrosion and electrolysis. Ultra flexible (Type 3) stranding resists fatigue due to vibration and flexing. ANCOR's proprietary premium vinyl insulation stays flexible even in extreme cold and resists salt water, battery acid, oil, gasoline and ultra-violet radiation. Exclusive insulation is rated at 600 volts, 105°C dry and 75°C wet, and is resistant to heat and abrasion. Exceeds all UL 1426, US Coast Guard Charter boat (CFR Title 46) and ABYC standards. WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
- They are constructed with premium vinyl insulation that is rated at 600 volts, 105 deg C dry and 75 deg C wet, stays flexible even in extreme cold (-40 deg F/C) and resists salt water, battery acid, oil, gasoline, heat, abrasion and ultra-violet radiation
- Exceeds all UL 1426, US Coast Guard Charter boat (CFR title 46) and ABYC standards
- Ultra-flexible Type 3 stranding resists fatigue from vibration and provides added corrosion protection
- Manufactured from individual copper strands and tinned to perform in the harshest marine environments
- 100 Feet of Black 12 AWG marine grade wire
Specifications:
| Materials & Construction | |
| Color | Black |
| Material | Tinned Copper |
| Outer Material | Tinned Copper |
| Product Details | |
| Global Trade Identification Number | 00091887106688 |
| Included Components | Ancor 106010 Primary Wire #12 AWG/3mm - Black, 100' |
| Model Number | 106010 |
| Number of Cable Strands | Multi Strand |
| Number of Items | 1 |
| Part Number | 106010 |
| Style | 12 Awg |
| UPC | 300717096168 091887106688 066510868158 |
| Sizing & Dimensions | |
| Height | 3.25 inches |
| Length | 4 inches |
| Product Dimensions | 4 x 4 x 3.25 inches |
| Size | 100 Feet |
| Weight | 2.9 pounds |
| Width | 4 inches |
| Technical Specifications | |
| No. of wires | 1 |
| Voltage | 600 Volts |
