Blue Sea Systems 7152 Marine Grade Short Stop Circuit Breaker, 15A
Customize
7152 Short Stop Circuit Breaker - 15A Corrosion Resistant Material IP 64 Water Resistant Boot Push to Reset Only Interrupt Capacity: 2,500A @ 28VDC Red insulating boot included in retail package Specifications Amperage: 15A DC Maximum Voltage: 28V DC Interrupt Capacity: 2500A @ 28V DC Minimum Operating Temperature: -10° C Maximum Operating Temperature: 60° C Screw Terminal Torque: 24 in-lb (2.71 Nm) Terminal Stud: #10-32" WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov ., Amperage: 15a. The Blue Sea Systems 7152-BSS Marine Grade Short Stop Circuit Breaker is constructed from corrosion-resistant materials to withstand harsh environments. The IP64 water resistant boot protects against dust and splashing water. Its push-to-reset operation only disconnects when tripped. Stainless steel lock nuts are provided for secure connections. Red insulating boot included. Amperage: 15A DC. Maximum Voltage: 28V DC. Circuit Breaker Type: Thermal Trip/Manual Reset. Interrupt Capacity: 2500A @ 28V DC. Minimum Operating Temperature: -10°C. Maximum Operating Temperature: 60°C. Terminal Stud: #10-32.
- Manufacturer Part Number: 7152-BSS
- Amperage: 15A
- Stainless steel lock nuts and red insulating boot included
- Push-to-reset operation only disconnects when tripped
- IP64 water resistant boot protects against dust and splashing water
- Corrosion resistant materials to withstand harsh environments
Specifications:
| Materials & Construction | |
| Color | Red (insulating boot) |
| Material | Corrosion Resistant Material |
| Outer Material | Corrosion Resistant Material |
| Product Details | |
| Circuit Breaker Type | Standard |
| Current Rating | 15 Amps |
| Manufacturer Part No | 7152 |
| Model Number | 7152-BSS |
| Mounting Type | Panel Mount |
| Number Of Poles | 1 |
| Style | Short Stop |
| Voltage | 28 Volts |
| Sizing & Dimensions | |
| Height | 4.44 inches |
| Length | 1.25 inches |
| Product Dimensions | 1.25 x 2.69 x 4.44 inches |
| Size | 1.25 x 2.69 x 4.44 inches |
| Weight | 0.96 ounces |
| Width | 2.69 inches |
| Technical Specifications | |
| Screw Terminal Torque | 24 in-lb (2.71 Nm) |
| Terminal Stud | #10-32 |
