Blue Sea 8043 AC Main +3 Positions Toggle Circuit Breaker Panel - White Switches
Customize
8043 AC Main +3 Positions Toggle Circuit Breaker Panel - White Switches Features: Red reverse polarity indicating LED All hot, neutral and safety ground buses installed, fully pre-wired All circuit label positions are backlit on standard panels - No kit required "ON" indicating LEDs installed in all circuit positions Specifications: Positions: 3 Nominal Voltage: 120v AC Height: 7.5" Width: 5.25" Included: (1) 8031 Basic AC Panel Label Set - 30 Labels (4) 8034 LED - 120v AC Green (1) 8066 LED - 120v AC Red (3) 7210 A-Series White Toggle Circuit Breaker - Single Pole 15A (Branch) (1) 7238 A-Series White Toggle Circuit Breaker - Double Pole 30A (Main) (1) 9353 AC Voltmeter - 0 to 150v AC (Meter) WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov .
- Red reverse polarity indicating LED
- All hot, neutral and safety ground buses installed, fully pre-wired
- Maximum panel amperage - 100 Amperes
Specifications:
| Materials & Construction | |
| Color | White |
| Material | Plastic |
| Point Style | Spear Point |
| Product Details | |
| Ac/dc | Ac |
| Included Components | PANEL AC TOGGLE/3 SWTCH/VM |
| Max Breaker Quantity | 3 |
| Number of Items | 1 |
| Number of Pieces | 1 |
| Point Style | Spear Point |
| Style | Safety |
| Voltage | 120v |
| Warranty Description | LIMITED WARRANTY |
| Sizing & Dimensions | |
| Height | 12 inches |
| Length | 4 inches |
| Product Dimensions | 4 x 7 x 12 inches |
| Size | 5-1/4" W x 7-1/2" H |
| Weight | 2 pounds |
| Width | 7 inches |
| Technical Specifications | |
| AC Voltmeter Range | 0 to 150v AC |
| Maximum panel amperage | 100 Amperes |
