TRAC-Outdoor Products Automatic Bilge Pump, 800/1100 GPH, 3/4" & 1-1/8" Outlet
Customize
The TRAC 69311 Automatic Bilge Pump is a robust 12V centrifugal, self-priming bilge pump designed for easy installation and retrofitting on watercraft. Featuring cartridge-style pump head and a universal strainer base compatible with Attwood Tsunami, Rule, and Johnson/Mayfair cartridge pumps, it accepts both 3/4" and 1-1/8" screw-on outlets (each outlet with O-ring). The pump is ignition protected, has a low power draw, and can run dry without damage. An integrated float switch provides automatic ON/OFF operation. Technical spec highlights: Automatic operation; 800 GPH (3/4" outlet) and 1100 GPH (1-1/8" outlet); 12 V operation; cartridge-style pump head; universal strainer base with side mounting option for tight spaces. Meets ABYC, NMMA, Coast Guard and ISO marine standards. Sold as an individual.
- Ignition protection; Low power draw; Runs dry without damage
- Universal strainer base is connection compatible: fits Attwood Tsunami, Rule, Johnson/Mayfair cartridge pumps; screw mounting holes match Rule and Attwood Tsunami; Strainer base also includes side mounting option for tight spaces
- Pump body accepts both 3/4” and 1-1/8” screw-on outlets to allow ease of installation; Each outlet has an O-ring for easy maneuverability without stripping
- Internal integrated float switch for AUTO ON/OFF functionality
- Cartridge style pump head
Materials & Construction
- Color:Black
- Material:Plastic
- Outer Material:Plastic
Product Details
- Amperage:3.7 Amps
- Item model number:69311
- Manufacturer Part No:3004.7234
- Power Source:['DC Power Supply']
- Style:Bilge Pump
Sizing & Dimensions
- Height:3 inches
- Length:5.5 inches
- Product Dimensions:5.5 x 7.5 x 3 inches
- Weight:14.4 ounces
- Width:7.5 inches
Technical Specifications
- Gallons Per Hour:800/1100 Gph
- Maximum Flow Rate:1.1E+3 Gallons Per Minute
- Operation:Automatic
- Type:Electric
- Voltage:12v
