Xantrex XM1000 Pro Series Inverter - 1000W
Customize
The Xantrex PRO Series XM1000 1000W inverter delivers reliable modified sine wave power for RV and marine applications when shore power is unavailable. Designed to complement generators or battery chargers, the PRO Series provides power for TVs, small appliances and onboard electronics. Features include a detachable digital remote to display inverter/AC source/battery status, built-in 15A circuit breaker on AC pass-through, up to 25A pass-through for hardwired loads, conformal coated electronics for moisture resistance, automatic transfer switch, overload and short-circuit protection, and built-in ground-fault protection. The inverter is UL 458 approved for RV/marine use and meets FCC Class B regulations. Installation options include hard-wiring via terminal strip or connecting AC through the included GFCI receptacle.
- Easily powers TVs, small appliances, and other electronics
- Built-in 15A circuit breaker on AC pass-through
- Digital remote control displays power output, AC source and battery voltage
- Detachable remote control can be mounted wherever convenient
- Designed to be hard-wired using a terminal strip or by connecting AC through a GFCI receptacle (included)
Specifications:
| Materials & Construction | |
| Conformal Coating | Conformal coated electronics (as noted in ProductDatabase Long Description) |
| Product Details | |
| Ac Connection Type | Hardwire |
| Dc Connection Type | Hardwire |
| Gfci | Yes |
| Inverter Cont. Output Wattage | 1000w |
| Inverter Input Voltage | 12v |
| Inverter Output Voltage | 120v |
| Inverter Surge Rating | 2000w |
| Manufacturer Part No | 3215 |
| Model | 806-1010 |
| Outlet Qty | 1 Duplex Gfci |
| Power Source | Battery Powered |
| Wattage | 1000.00 |
| Waveform | Modified Sine Wave |
| Sizing & Dimensions | |
| Height | 12 inches |
| Length | 20.5 inches |
| Product Dimensions | 20.5 x 15.5 x 12 inches |
| Weight | 7.7 pounds |
| Width | 15.5 inches |
| Technical Specifications | |
| AC Pass-Through | Up to 25A for hardwired loads |
| Built-in Circuit Breaker | 15A |
| Protection Features | Battery over-voltage/under-voltage, over temperature, overload, short-circuit, ground fault |
| Transfer Switch | Built-in automatic transfer switch |
