3M 35-Orange-1/2x20FT Color Coding Electrical Tape, Vinyl, Orange, 1/2" x 20'
3M vinyl color-coding electrical tape, 1/2 in x 20 ft (7 mil). Orange vinyl tape for insulating, color-coding and safety coding; waterproof, 600V (1250 V/mil dielectric), operating temp 32°F to 220°F.
$6.03
Customize
Available Quantity
814 GSA Item
Yes GSA Compliant
Yes Product Details
3M 35 Series Orange vinyl electrical color-coding tape. 1/2" width x 20' length with 7 mil thickness. Designed for professional use with rubber adhesive and vinyl backing for reliable insulation, color coding and safety marking. Dielectric strength 1250 V/mil (600V nominal rating), tensile strength 17 lb/in. Meets CSA C22.2 No. 197, UL 510 and VDE 0340 requirements. Applications include color coding, insulating, protecting, safety coding and wrapping. Temperature range 32°F to 220°F (0°C to 104.44°C). Series: 35. Length range 6 to 11.9 yd (20 ft / 6.10 m). Width approximately 1/2" (12 mm).
- Made in US
Specifications:
| Materials & Construction | |
| Adhesive Material | Rubber |
| Color | Orange |
| Material | Vinyl |
| Product Details | |
| Adhesive Material | Rubber |
| Applications | Color Coding; Insulating; Protecting; Safety Coding; Wrapping |
| Item model number | 80610834014 |
| Number of Items | 1 |
| Series | 35 |
| Series Part Number | 35 |
| Standards | Csa Certified; Standard C22.2 No. 197- M1983 PVC Insulating Tape (File Lr48769); Ul 510 File E129200; Vde 0340-Teil1 |
| Tensile Strength (Lb./Inch) | 17.00 |
| Water Resistance Level | Waterproof |
| Sizing & Dimensions | |
| Height | 2 inches |
| Length (Meters) | 6.10 |
| Length Ft. | 20.00 |
| Length Range | 6 To 11.9 yd |
| Length | 6 inches |
| Product Dimensions | 6 x 2 x 2 inches |
| Thickness (Mil) | 7.0000 |
| Weight | 1 pounds |
| Width (Inch) | 1/2 |
| Width | 2 inches |
| Technical Specifications | |
| Dielectric Strength (V/Mil) | 1250.00 V/mil |
| Maximum Operating Temperature C | 104.44 |
| Maximum Operating Temperature F | 220.00 |
| Minimum Operating Temperature C | 0.00 |
| Minimum Operating Temperature F | 32.00 |
| Tensile Strength (Lb./Inch) | 17.00 |
