Monoprice Rotary Wall-Plate Speaker Volume Controller, Single-Gang, White
Monoprice rotary wall-plate speaker volume controller with 12-position rotary control; mounts in a single-gang low-voltage bracket and supports 4–16 ohm speakers.
Out of stock
$20.99
$20.99
Color
Customize
Available Quantity
20 GSA Item
No GSA Compliant
No Product Details
This Monoprice rotary wall-plate speaker volume controller provides a compact in-wall solution for adjusting speaker volume. The unit uses a 12-position rotary control (including minimum/off and maximum positions) and mounts into a standard single-gang low-voltage bracket (bracket not included). It offers screw terminal connections for one pair of stereo speaker wires with four input and four output connections and accepts 14–16 AWG wire. Designed for use with 4–16 ohm speakers, the controller delivers a frequency response of 35Hz–20kHz (+0/-2dB), making it suitable for home theater, stereo and surround sound setups that require convenient, wall-mounted volume control.
- Please note: This volume control does not include a wall mounting bracket
- This rotary control can be set-Inch one of twelve positions including the minimum (off) and maximum volume settings
- The MVR-100 is a rotary-type wall plate volume control for speaker systems with power ratings of up to 100 watts per channel and impedance ratings of 4 - 16 ohms
Specifications:
| Product Details | |
| Connectivity Protocol | Zigbee |
| Controller Type | Volume control |
| Country of Origin | China |
| Included Components | 1x Speaker Volume Controller |
| Is Waterproof | FALSE |
| Item model number | 108243 |
| Model Name | MVR-100 |
| Number of Items | 1 |
| Power Source | Corded Electric |
| Recommended Uses For Product | For Surround Sound Systems |
| Speaker Size | 4 Inches |
| Speaker Type | Multi Room |
| Special Feature | Multi Room Audio |
| Specific Uses For Product | Speaker |
| Style | 100W |
| Surround Sound Channel Configuration | 2.0 |
| Unit Count | 1.0 Count |
| Wireless Communication Technology | Infrared |
| Sizing & Dimensions | |
| Height | 4.9 inches |
| Length | 2.75 inches |
| Product Dimensions | 2.75"D x 2.1"W x 4.9"H |
| Weight | 1.22 pounds |
| Width | 2.1 inches |
| Technical Specifications | |
| Audio Output Mode | Stereo |
| Connectivity Technology | Wireless, IR |
| Mounting Type | Wall Mount |
| Speaker Maximum Output Power | 100 Watts |
