Blue Sea 7485 360 Panel - Rocker Switch SPDT - (ON)-OFF-(ON)
Customize
The Blue Sea Systems 7485 is a SPDT rocker switch module designed for the 360 Panel System. It features (ON)-OFF-(ON) action (with () indicating momentary ON), quick-connect tab terminals (0.187" / 4.75mm), and a compact panel-mount form that allows easy integration into Blue Sea 360 panel modules such as Gauge, DC Push Button + Switch, and DC Battery Management. Rated for multiple voltages and currents (10A @ 12V DC; 8A @ 24V DC; 8A @ 125V AC; 8A @ 250V AC), the 7485 provides reliable switching for marine and panel-based electrical systems. The open-frame 360 Panel System supports rapid assembly and a wide choice of modules to accommodate battery management, source selection and other panel functions. Constructed for durability and secure panel retention (wings that hold the switch into the panel), the switch is supplied in black and is suitable for panel-mounted installations. International Protection Rating: IP54. Mounting type: panel mount. Terminal type: quick connect. Item dimensions: 5 x 3 x 1 inches. Package dimensions: 3.6 x 2.5 x 0.6 inches.
- Combines switching and circuit protection into a single device
- Action: (On)-Off. () = Momentary
- Wings hold switch into panel without additional hardware
- For use in 360 panels in the following modules: Gauge, DC Push Button + Switch and DC Battery Management
- Terminal Type: Quick Connect, Max Amp: 10A @ 12V DC, 8A @ 24V DC, 8A @ 125V AC, 8A @250V AC
Specifications:
| Materials & Construction | |
| Color | Black |
| Product Details | |
| Actuator Type | Push Button |
| Connectivity Protocol | X-10 |
| Connector Type | Quick Connect |
| Controller Type | Push Button |
| Current Rating | 30 Amps |
| Included Components | Great Product |
| International Protection Rating | IP54 |
| Mounting Type | Panel Mount |
| Number of Positions | 11 |
| Operating Voltage | 250 Volts |
| Operation Mode | Push Button |
| Style | Spdt, (On)-off-(on) |
| Terminal | Button,quick Connect |
| Warranty Description | Warranty |
| Sizing & Dimensions | |
| Height | 1 inches |
| Length | 5 inches |
| Product Dimensions | 5 x 3 x 1 inches |
| Size | 1/2-Inch Diameter |
| Weight | 0.01 ounces |
| Width | 3 inches |
| Technical Specifications | |
| Warranty | Warranty |
