Leviton 30 Amp, 125 Volt, NEMA L5-30P, 2P, 3W, Locking Plug, Industrial Grade, Grounding, 2611, Black-White
LEVITON 2611 locking NEMA L5-30P plug — 30A, 125V industrial-grade nylon body with grounding. Chemical- and impact-resistant construction for heavy-duty power connections in industrial environments.
$61.90
Customize
Available Quantity
52 GSA Item
No GSA Compliant
No Product Details
Locking Inlet: Plug, Industrial, L5-30P, 125V, Black & White. Leviton 2611 30 Amp, 125 Volt, NEMA L5-30P, 2P, 3W, locking plug designed for industrial grade performance and long-lasting reliability. Constructed of super-tough nylon to resist impact and chemical exposure, featuring self-grounding design, solid brass blades and contacts for improved conductivity and low heat. Internal wiring chambers isolate conductors to prevent flashover and arcing. Deep slotted triple drive face module and cord clamp screws. Includes cord clamp and secure wiring features; NEMA L5-30P configuration. Backed by Leviton's limited lifetime warranty. Applications: heavy-duty power connections, industrial equipment, generators, and other NEMA-compatible devices.
- Deep slotted triple drive face module and cord clamp screws
- Internal Wiring Chambers Isolate Individual Conductors to Prevent Flashover, Arcing, and Stray Strands of Wire
- Solid Brass Blades And Contacts Feature Improved Conductivity, Low Resistance, Low Heat, and Long Life
- NEMA and Non-NEMA Configurations Available
- Super Tough Nylon Body Resists Damage From Severe Impact, Abrasion and Chemicals
Specifications:
| Materials & Construction | |
| Color | Black, White |
| Material | Nylon |
| Outer Material | Nylon |
| Product Details | |
| Amperage | 30 |
| Color | Black, White |
| Connector Type | Plug |
| Country of Origin | China |
| Finish | Black, White |
| Grade | Industrial |
| Grounding Style | Self-Grounding |
| Included Components | 2611 |
| Item Package Quantity | 1 |
| Material | Nylon |
| Maximum Cord Diameter (Decimal Inch) | 0.8600 |
| Minimum Cord Diameter (Decimal Inch) | 0.3850 |
| Nema Configuration | L5-30p |
| Number Of Phases | 1 |
| Number Of Pieces | 1 |
| Number Of Poles | 2 |
| Number Of Wires | 3 |
| Part Number | 2611 |
| Plug Format | NEMA L5-30P |
| Power Source | Wired Electric |
| Resistance Features | Chemical Resistant; Impact-Resistant |
| Specification Met | NEMA |
| Standards | Ansi C-73; Csa C22.2 No. 42 File Lr-406; Csa Certified; Nema Wd-6; Nom 057; Ul 498 File E13393; Ul Federal Specification W-C-596 File E13393; Ul Listed |
| Thickness | 1 Inches |
| UPC | 078477807989 |
| Voltage | 125v |
| Warranty Description | Limited Lifetime |
| Sizing & Dimensions | |
| Height | 8 inches |
| Length | 8 inches |
| Product Dimensions | 8 x 8 x 8 inches |
| Size | One Size |
| Weight | 4.5 ounces |
| Width | 8 inches |
| Technical Specifications | |
| Warranty | Limited Lifetime |
